ST Fiber Optic Connector
Home » Products » FTTx Solutions » Fiber optic connector » ST Fiber Optic Connector
Share to:

ST Fiber Optic Connector

Delivery Date: 7-working days Brand Name: T&J
Connector type: ST Fiber core: simplex
Fiber type: SM / MM Material of housing: Metal
Material of boot: plastic Boot color: Black / Blue / Green / Beige or on request
Ferrule: Ceramic Dimension: 0.9mm, 2.0mm, 3.0mm
Origin: China

ST/PC Simplex Optical Fiber Connector


Applications:

Local Area Networks (LANs)

Data processing networks

Premise installations

Instrumentation


Specifications:

Boots size: 900um, 2.0mm, 3.0mm

Polish Type: SM, MM, and APC

Connectors: Simplex

Bayonet style housing for easy termination

Epoxy and epoxy-less versions

High precision alignment

Low insertion, high return loss and back reflection

Compliance with Telcordia, ANSI, IEC, TIA/EIA, NTT and JIS spec.


Specifications

Parameter

Unit

LC,SC,FC,MU,ST, SC-ST,FC-ST,  FC-SC,   FC-LC, FC-MU

MTRJ

E2000

SM

MM

SM

MM

SM

PC

UPC

APC

PC

PC

UPC

PC

PC

APC

Insertion Loss (Typical)

db

≤0.3

≤0.2

≤0.3

≤0.2

≤0.3

≤0.2

≤0.2

≤0.2

≤0.3

Return   Loss

db

≥45

≥50

≥60

≥30

≥45

≥50

≥35

≥55

≥75

Exchangeability

db

≤0.2

≤0.2

≤0.2

Repeatability

db

≤0.2

≤0.2

≤0.2

Durability

time

>1000

>1000

>1000

Operating   Temperature

-40~+75

-40~+75

-40~+75

Storage   Temperature

-45~+85

-45~+85

-45~+85

ST series fiber optic connectors


ST/PC fiber optic connector



Packing: 1 piece / polybag.

Customer's brand or LOGO available to stick on the polybag.

Or customed polybag available.


ST Optical Fiber Connector
