GJFJZY-2B1 Singlemode Duplex Indoor Fiber Cable
Home » Products » FTTx Solutions » Fiber optic cable » GJFJZY-2B1 Singlemode Duplex Indoor Fiber Cable

loading

Share to:
sharethis sharing button

GJFJZY-2B1 Singlemode Duplex Indoor Fiber Cable

  • GJFJZY-2B1

  • Fibertel

Availability:
Delivery Date:7 working daysBrand Name:T&J
Model 1:GJFJV for PVC jacketModel 2:GJFJZY for LSZH jacket
Fiber type:SM / MMFiber Count:2
Dynamic Min.Bending Radius(mm):100Static Min.Bending Radius(mm):30
Jacket material:PVC or LSZHJacket color:yellow or orange
construction:RoundOrigin:China

The duplex round cable is cabled with a PVC sheath or LSZH material after the single-mode or multi-mode double-core tight-buffered optical fiber claded with a high-strength aramid yarn layer.


Applications:

Ideal for interconnect applications for instruments and communication equipments

Used in indoor cabling


Technical Parameters(Typical Values):

Fiber CountO.D. (mm)Tensile Strength (N)Tensile Strength (N)Crush (N/100mm)Crush (N/100mm)Min.Bending Radius(mm)Min.Bending Radius(mm)Cable Weight


Short TermLong TermShort TermLong TermDynamicStatic(kg/km)
24.550030010002001003017.8
24.222014010002001003015.2
23.6200130500100100309.0
23.2200130500100100307.1
23.015080500100100306.6
22.515080500100100304.8



Ordering Information:


1) Outer Jacket Material:
V - PVC
Z - LSZH

2) Outer Jacket Color:
Single mode- Yellow
Multimode- Orange
OM3- Aqua

3) Tight Buffer Color:
B- Blue
O- Orange
G- Green
N- Brown
S- Slate
W- White
R- Red
K- Black
Y- Yellow
V- Violet
P- Pink
A- Qqua

4) Fiber Type:
B1- G.652
B1.3- G.652.D
B4- G.655
E1- EasyBand G.657
E1.1- EasyBand Plus G.657
A1- 50/125um
A1b- 62.5/125um
A1H- HiBand 50/125um
A1bH - HiBand 62.5/125um
M1- MaxBand 150
M3- MaxBand 300
M5- MaxBand 550

5) Delivery Length:
   Standard Reel Length is 2000meters, Other length available on request
