GJBFJH-48B Single mode indoor breakout Cable 48 fibers

GJBFJH-48B Single mode indoor breakout Cable utilizes 48 sub-unit of 2.0mm simplex single mode optical cable, and protected with a PVC outer jacket.
  • GJBFJH-48B

  • Fibertel

Availability:
Delivery Date:7 working daysBrand Name:T&J
Model No.:GJBFJH-48BFiber type:SM G.652D / G.657A
Fiber Count:48 fibersSub-cable diameter:2.0mm
Application:Indoor break-out cableDynamic Min.Bending Radius(mm):20D
Jacket material:PVCJacket color:Yellow
Operation temperature:-20~+70COrigin:China

GJBFJH-48B Single mode indoor breakout Cable utilizes 48 sub-unit of 2.0mm simplex single mode optical cable, and protected with a PVC outer jacket.


Applications:

Ideal for intra-building backbone cabling including floors, terminal boxes and work stations

Ideal for short and middle distance direct terminals in intra-buildings and within different buildings, each sub-cable unit can be directly connected by standard connector.


Technical Parameters(Typical Values):Sub-cable Diameter: 2.0mm
Single Layer:

Fiber CountO.D. (mm)Tensile Strength (N)Tensile Strength (N)Crush (N/100mm)Crush (N/100mm)Min.Bending Radius(mm)Min.Bending Radius(mm)Cable Weight


Short TermLong TermShort TermLong TermDynamicStatic(kg/km)
46.6430210100030020D10D37
67.8590290100030020D10D55
89.0980490100030020D10D74
1010.71140570100030020D10D104
1211.91300650100030020D10D131

Dual Layer:

Fiber CountO.D. (mm)Tensile Strength (N)Tensile Strength (N)Crush (N/100mm)Crush (N/100mm)Min.Bending Radius(mm)Min.Bending Radius(mm)Cable Weight


Short TermLong TermShort TermLong TermDynamicStatic(kg/km)
1411.01200600100030020D10D98
1611.61380690100030020D10D110
1812.21540770100030020D10D122
2012.81930960100030020D10D136
2213.420901040100030020D10D149
2414.022501120100030020D10D164
3017.027001300100030020D10S250

Triple Layer:

Fiber CountO.D. (mm)Tensile Strength (N)Tensile Strength (N)Crush (N/100mm)Crush (N/100mm)Min.Bending Radius(mm)Min.Bending Radius(mm)Cable Weight


Short TermLong TermShort TermLong TermDynamicStatic(kg/km)
3617.529001400100030020D10D245
4819.541002000100030020D10D320



Ordering Information:


1) Outer Jacket Material:
GJBFJV cabled with PVC outer jacket
GJBFJH cabled with LSZH outer jacket

2) Inner / Outer Jacket Color:
Single mode (SM) - Yellow
Multimode (MM) - Orange
OM3 - Aqua

3) Tight Buffer Color:
12 colors available: Blue / Orange / Green / Brown / Slate / White / Red / Black / Yellow / Violet / Pink / Aqua

4) Fiber Type:
SM - G.652D / G.655 / G.657A
MM - OM1 / OM2 / OM3-150 / OM3-300 / OM3-450

5) Subunit Cable Diameter: 2.0mm

6) Cable Pringting:
Model + Optical Fiber Cable + fiber type + fiber count + Length mark
Or on request with OEM brand.

7) Package:
1KM per drum (see below image), or on request
