Technical Parameters
Model | Diameter (mm) | Voltage (v) | Frequency (Hz) | Speed (r/min) | Watts (w) | Capacity (m3/min) | Static (Pa) | Noise dB(A) |
TJ06VP08A | 200 | 110 | 50/60 | 2800/33 00 | 180/230 | 25/30. | 245/295 | 61 |
TJ06VP08B | 200 | 220~240 | 50/60 | 2800/33 00 | 180/230 | 25/30 | 245/295 | 61 |
TJ06VP10A | 250 | 110 | 50/60 | 2800/33 00 | 300/350 | 45/55 | 295/350 | 66 |
TJ06VP10B | 250 | 220~240 | 50/60 | 2800/33 00 | 300/350 | 45/55 | 295/350 | 66 |
TJ06VP12A | 300 | 110 | 50/60 | 2800/33 00 | 500/550 | 65/77 | 385/450 | 69 |
TJ06VP12B | 300 | 220~240 | 50/60 | 2800/33 00 | 500/550 | 65/77 | 385/450 | 69 |
Technical Parameters
Model | Diameter (mm) | Voltage (v) | Frequency (Hz) | Speed (r/min) | Watts (w) | Capacity (m3/min) | Static (Pa) | Noise dB(A) |
TJ06VP08A | 200 | 110 | 50/60 | 2800/33 00 | 180/230 | 25/30. | 245/295 | 61 |
TJ06VP08B | 200 | 220~240 | 50/60 | 2800/33 00 | 180/230 | 25/30 | 245/295 | 61 |
TJ06VP10A | 250 | 110 | 50/60 | 2800/33 00 | 300/350 | 45/55 | 295/350 | 66 |
TJ06VP10B | 250 | 220~240 | 50/60 | 2800/33 00 | 300/350 | 45/55 | 295/350 | 66 |
TJ06VP12A | 300 | 110 | 50/60 | 2800/33 00 | 500/550 | 65/77 | 385/450 | 69 |
TJ06VP12B | 300 | 220~240 | 50/60 | 2800/33 00 | 500/550 | 65/77 | 385/450 | 69 |
