Description:
SC fiber adapter
Length: 40MM/ diameter: 13MM
Change < 0.2dB in cycle test (-40~+80℃)
It is easy to operate and can be observed by naked eyes
Reusable, single/multi-mode fiber can be used
Small loss, excellent reflection inhibition
Suitable for emergency repair and temporary connection of optical fiber
There is no epoxy glue or any medium in the core and through hole of bare fiber adapter
It is easy to insert, pull out and reuse bare fiber, and has low insertion loss
Fiber type | SC Fiber Optic Adaptors |
Insertion Loss | ≤0.2dbB |
Repeatability | ≤0.2dbB |
≤0.2dbB | |
· Insert core diameter | 125-127μm |
Exchangeability | ＞1000次 |
Working Temperature | -40℃~80℃ |
Weight | 15g |
Description:
SC fiber adapter
Length: 40MM/ diameter: 13MM
Change < 0.2dB in cycle test (-40~+80℃)
It is easy to operate and can be observed by naked eyes
Reusable, single/multi-mode fiber can be used
Small loss, excellent reflection inhibition
Suitable for emergency repair and temporary connection of optical fiber
There is no epoxy glue or any medium in the core and through hole of bare fiber adapter
It is easy to insert, pull out and reuse bare fiber, and has low insertion loss
Fiber type | SC Fiber Optic Adaptors |
Insertion Loss | ≤0.2dbB |
Repeatability | ≤0.2dbB |
≤0.2dbB | |
· Insert core diameter | 125-127μm |
Exchangeability | ＞1000次 |
Working Temperature | -40℃~80℃ |
Weight | 15g |
