Fibertel
| Item | Description |
| Connector | SC/UPC or SC/APC,SM per IEC 61754-4 |
| Cable | 2.0*3.0mm LSZH non-flame retardant, black |
| Type length | Any lengths as per request |
| Length of Tolerance | L<=10m @+200mm 10<L<=50m @+500mm L>50m @1% |
| Insertion Loss | <=0.3dB |
| Return Loss | =>55dB |
| Durability | 500 times, the insertion loss change <=0.2dB |
| Operation Temperature | -20℃ to + 60℃ |
| Storage Temperature | -20℃ to + 70℃ |
| Installation Temperature | -5℃ to + 50℃ |
| Item | Description |
| Connector | SC/UPC or SC/APC,SM per IEC 61754-4 |
| Cable | 2.0*3.0mm LSZH non-flame retardant, black |
| Type length | Any lengths as per request |
| Length of Tolerance | L<=10m @+200mm 10<L<=50m @+500mm L>50m @1% |
| Insertion Loss | <=0.3dB |
| Return Loss | =>55dB |
| Durability | 500 times, the insertion loss change <=0.2dB |
| Operation Temperature | -20℃ to + 60℃ |
| Storage Temperature | -20℃ to + 70℃ |
| Installation Temperature | -5℃ to + 50℃ |
