Usage and safety regulation:
Before using optical fiber cleaver, please read this manual carefully;
Be cautious to use cleaver in case harm;
Do not touch the blade with hand when use or repair optical fiber cleaver;
Do not take down or oil cleaver;
Keep optical fiber cleaver away from humid and dusty environment.
Technical specifications:
Applicable range | Single Core silex-fiber |
Coating Diameter | φ0.25mm ＆φ0.9mm |
Fiber Diameter | 125μm |
Cleave Length | 9~16mm(φ0.25) 10~16(φ0.9) |
Dimension | 59mm(W)*55mm(D)*49mm(H) |
Weight | 255g |
Cleaving Angle | ≤0.5° |
Blade Life | 16000 times |
