Name: Pole Clamp Stainless Steel Screw Type TJ06A2B01
Brand: Fibertel
Rating: 5.0 (22 reviews)

Pole Clamp Stainless Steel Screw Type TJ06A2B01

Home » Products » FTTx Solutions » Installation accessories » Pole Clamp Stainless Steel Screw Type TJ06A2B01

PRODUCTS

Fibertel provides a simple pole mounting solution - Pole Clamps are made of High-grade stainless steel, it has Screw-tightened and Quick release types, with diameter from minimum 6mm to maximum 900mm.

Stainless Steel Pole Clamp Screw Type Pole Clamp 201 304 stainless

RECOMMRND PRODUCTS

Protective Guide E TJ07RA017

Rubber Seal End Capof Pipeline TJ06OECxx

Straight Protector TJ06A1028

Corner Protector TJ06A1027

Corner Protector TJ06A1026

Wall Cross Sleeve TJ06A1025

Mounting Clip TJ06A1024

Screw Fasterning TJ06A1023

Cable Clip TJ06A1022

Cable Retractor TJ06A1021

Cable Retractor TJ06A1020

Pole Clamp Oval TJ06A1011

Pole Clamp Round TJ06A1009

Cable Coiling Ring TJ06A1019

Nail Wall Wire Clamp TJ06A1008

Anchor Wire Clamp TJ06A1005

Cable Retractor TJ06A1002

Cable Retractor TJ06A1001

Extension Cable Reel TJ07ER25A

2 inch Flat Type Hose TJ07WPH2B

Specification	Band Width	Min. Diameter	Max, Diameter	Steel Belt Length	Area on Belt with Holes	unit
6-12	8	6	12	52	All Length	mm
10-16	8	10	16	60	All Length	mm
13-19	8	13	19	68	All Length	mm
16-25	8	16	25	88	All Length	mm
19-29	8	19	29	100	All Length	mm
13-23	12	13	23	90	All Length	mm
14-27	12	14	27	92	All Length	mm
18-32	12	18	32	108	All Length	mm
21-38	12	21	38	138	80	mm
21-44	12	21	44	150	90	mm
27-51	12	27	51	168	107	mm
33-57	12	33	57	186	107	mm
40-63	12	40	63	206	107	mm
46-70	12	46	70	230	107	mm
52-76	12	52	76	250	107	mm
59-82	12	59	82	265	107	mm
65-89	12	65	89	288	107	mm
72-95	12	72	95	305	107	mm
78-101	12	78	101	328	107	mm
84-108	12	84	108	350	107	mm
91-114	12	91	114	365	107	mm
105-127	12	105	127	410	107	mm
118-140	12	118	140	448	107	mm
130-152	12	130	152	485	107	mm
141-165	12	141	165	524	107	mm
155-178	12	155	178	564	120	mm
175-197	12	175	197	656	240	mm
194-216	12	194	216	688	240	mm
213-235	12	213	235	746	240	mm
232-254	12	232	254	805	240	mm
251-273	12	251	273	863	240	mm
270-292	12	270	292	924	240	mm
289-311	12	289	311	985	240	mm
300-400	12	300	400	1264	360	mm
400-500	12	400	500	1575	360	mm
150-250	12	150	250	790	360	mm
250-350	12	250	350	1100	360	mm
350-450	12	350	450	1718	360	mm
450-550	12	450	550	1732	360	mm
500-600	12	500	600	1870	360	mm
600-700	12	600	700	2200	480	mm
700-800	12	700	800	2515	480	mm
800-900	12	800	900	2830	600	mm

Specification	Band Width	Min. Diameter	Max, Diameter	Steel Belt Length	Area on Belt with Holes	unit
6-12	8	6	12	52	All Length	mm
10-16	8	10	16	60	All Length	mm
13-19	8	13	19	68	All Length	mm
16-25	8	16	25	88	All Length	mm
19-29	8	19	29	100	All Length	mm
13-23	12	13	23	90	All Length	mm
14-27	12	14	27	92	All Length	mm
18-32	12	18	32	108	All Length	mm
21-38	12	21	38	138	80	mm
21-44	12	21	44	150	90	mm
27-51	12	27	51	168	107	mm
33-57	12	33	57	186	107	mm
40-63	12	40	63	206	107	mm
46-70	12	46	70	230	107	mm
52-76	12	52	76	250	107	mm
59-82	12	59	82	265	107	mm
65-89	12	65	89	288	107	mm
72-95	12	72	95	305	107	mm
78-101	12	78	101	328	107	mm
84-108	12	84	108	350	107	mm
91-114	12	91	114	365	107	mm
105-127	12	105	127	410	107	mm
118-140	12	118	140	448	107	mm
130-152	12	130	152	485	107	mm
141-165	12	141	165	524	107	mm
155-178	12	155	178	564	120	mm
175-197	12	175	197	656	240	mm
194-216	12	194	216	688	240	mm
213-235	12	213	235	746	240	mm
232-254	12	232	254	805	240	mm
251-273	12	251	273	863	240	mm
270-292	12	270	292	924	240	mm
289-311	12	289	311	985	240	mm
300-400	12	300	400	1264	360	mm
400-500	12	400	500	1575	360	mm
150-250	12	150	250	790	360	mm
250-350	12	250	350	1100	360	mm
350-450	12	350	450	1718	360	mm
450-550	12	450	550	1732	360	mm
500-600	12	500	600	1870	360	mm
600-700	12	600	700	2200	480	mm
700-800	12	700	800	2515	480	mm
800-900	12	800	900	2830	600	mm

Availability:



Inquire Add to Basket
