Confidex Steelwave Micro II Rfid Tag

Delivery Date: 7-working days Name: Steelwave Micro II
Tag Form Factor: Hard Tag Tag Materials: Engineering plastics, synthetic face layer
Operating Frequency: 865 - 868 (ETSI) / 902 - 928 (FCC) Reading Range: Up to 5 meters on-metal
Transponder Protocols: EPC Class1 Gen2 Operating Temperature: -20° to +70°C
Dimensions: 38 x 13 x 4.5 mm Weight: 2 g
Origin: China

Confidex Steelwave Micro II Rfid Tag

Confidex Steelwave Micro II Rfid Tag

Confidex Steelwave Micro II™ is a small-sized UHF all-surface tag, which for its size provides unique performance. Confidex Steelwave Micro II™ peak performance is achieved when tag is attached on-metal. However, it can be very well used on any surface or even hanging. Versatile attachment options make this small product a real All-Around indoor asset tag and enables new possibilities in ICT and electronics tracking.


ELECTRICAL:

Air Interface Protocol EPCglobal UHF Class 1 Gen 2 (ISO 18000-6C)
Operating Frequency Global (865-928 MHz)
IC Type Impinj Monza 4QT™
Memory EPC 128 bit, User 512 bit, TID 48 bit
EPC Memory Content Unique, randomized number
Max Read Distance - On Metal Up to 5 m (16 ft)
Max Read Distance - Off Metal Up to 1.5 m (5 ft)
Applicable Surface Materials Any material

MECHANICAL:

Tag Form Factor Hard Tag
Tag Materials Engineering plastics, synthetic face layer
Attachment Method High performance acrylic adhesive
Dimensions 38 x 13 x 4.5 mm (1.5 x 0.5 x 0.17 in)
Weight 2 g
ENVIRONMENT:
Operating Temperature -20° to +70°C (-4° to +158°F)


Details:

Confidex Steelwave Micro II Rfid Tag


Confidex Steelwave Micro II Rfid Tag
